Specifications

Special Features

• Professional high-integration, optimum reliability electronics
• D.S.P. analysis with numeric filter of the signal received
• High immunity demodulation of the signals
• Exceptional discrimination
• Immediately-available display of security level
• Chip card system for direct selection of the operating mode, according to International Security Standards or customer requirements. The use of the card may be protected by password
• Programmability of all the parameters protected by passwords
• Very reduced analysis time for a rapid flow-rate (2 seconds)
• Automatic synchronisation between 2 or more devices with a reciprocal distance of down to 1 m without the use of cables
• Capacity for total remote control through an RS-232C serial line
• Automatic adjustment to environmental parameters and absence of initial or periodic calibrations.
• Proper environmental installation checked by means of a read-out of the general noise “GN” and electromagnetic noise “EN”.
• Complete interchangeability of electronics units and antennae thanks to the repeatability of the manufacturing processes
• Functionality tests can be carried out using accessory kit

Central Electronics Unit

• Degree of protection: IP 20 (IEC 529), with standard casing
• Dimensions and weight: IP 20: 380 x 157 x 82 mm; 1,5 kg

Installation Data

• Power supply: 115/230V ˜ ±15%, , 50 … 60 Hz, 30 VA
• Serial interface: RS-232C type with low impedance for connection to terminal, computer or external modem at a distance of up to 100 m
• Working temperature: -20 to +70°C
• Storage temperature: -35 to +70°C
• Relative humidity: 0 to 95%, without condensation
• Designed and built using advanced technological criteria, the probe is extremely robust and stable, yet elegant and fully protected against the effects of weather and wear-and-tear
• Total weight: 60 kg

Signalling

• Display of use instructions
• Detection of metallic masses
• Sabotage or internal self-diagnosis
• Visual: fixed or proportionate to the mass in transit - visible from 6m under lighting of 4000lux.
• Audio: programmable up to 90 dB(A) at 1m

Certification and Conformity

• Certified as harmless to wearers of pacemakers, invalids, pregnant women and so forth.
• Harmless to magnetic media
• Conforms to the detection requirements of EU Reg. N°1862/2006
• Conforms to the provisions of EU Reg N°857/2005 for Airport Security
• Conforms to the international standards currently applicable for electrical safety and EMC, and to the applicable EC Regulations.
• Conforms to all Airport Security Standards worldwide
